TIME ALPE D'HUEZ X

Alpe d’Huez X – The Modern Multi-Surface Road Bike

Introducing the Alpe d’Huez X – a masterclass in modern road cycling performance. This frameset represents the pinnacle of agility, comfort, and versatility. Designed to accommodate wider road tires, it provides confident handling on rougher surfaces while retaining the snappy acceleration needed for spirited group rides.

Whether you’re tackling steep climbs, rough tarmac, or long-distance routes, the Alpe d’Huez X delivers a refined ride experience that inspires you to do it all over again tomorrow.

⸻

FRAME SPECIFICATIONS

Frame Material
BCS Carbon Fiber – Reinforced with Vectran® and Dyneema® for exceptional strength and vibration damping.

Thru Axles
• Front: 12x120mm x 1.5mm pitch
• Rear: 12x159mm x 1.5mm pitch

Available Sizes
XS / SM / MD / LG / XL

Seatpost Diameter
ø27.2mm

Fork Steerer Tube
Tapered 1-1/8” to 1-1/2”

Seatpost Clamp
Proprietary TIME alloy clamp

Headset Bearings
Top and Bottom: 1-1/2” with internal routing compression ring

Shifting Compatibility
Supports both electronic and mechanical drivetrain systems

Wheel Size
700c

Front Derailleur Compatibility
1X and 2X wide compatible
Includes integrated single cover and drivetrain conversion kit

Maximum Tire Width
700x28–38c (Optimized for 32–35c)
Note: Compatibility may vary by tire/rim combination – always verify clearance

Rear Derailleur Mount
Standard

Bottom Bracket Standard
PF BB386

Brake Type
Flat Mount Disc – Front and Rear

Disc Hub Standard
• Front: 12x100mm
• Rear: 12x142mm

Rotor Size
140mm or 160mm with adapter
